CM D.62-B-W.75-Ball nose endmills (HELIBALL).

Dostępność: duża ilość

Cena brutto: 971,37 zł

zawiera 23,00% VAT, bez kosztów dostawy

Cena regularna:

971.37

Cena netto: 789,73 zł

bez 23,00% VAT i kosztów dostawy

Cena regularna:

Cena w innych sklepach: 1 079,30 zł

ilość szt.

towar niedostępny

dodaj do przechowalni

Ocena:

Producent:

Kod produktu: 3100611

CM D.62-B-W.75

Podstawowe informacje
FamilyName	CM D.31-1.00
ToolType	Tool
Unit	I
PackSize	1
product_code	ISC3100611
ProductName	CM D.62-B-W.75
COO	Israel
UOM	EA
UNSPSC	23242106
FamilyDesc	Ball nose endmills (HELIBALL).
FamilyShortDesc	Ball Nose Endmills
Link	https://www.Iscar.com/ecat/e.asp?cat=3100611
Remarks	For adaptation, click on More Info.
FamilyBrand	Iscar
BrandName	Iscar
Application	\| Profiling \|
APP1Name	Profiling
ItemRemark
Tool Type	Ball nose endmills
Point Shape
Measurement Type	Inch
Thread Standard
Package Weight	0.8510
Style
MSDS	07995
LocalField1	2
Body Material	Steel
ManufacturerNo	3100611
Body Half Taper Angle (BHTA)	2 Degrees
Connection Diameter Machine Side (DCONMS)	3/4"
Corner Radius (RE)	0.315"
Cutting Diameter (DC)	5/8"
Cutting Diameter (DC/DCX)	5/8"
Cutting Direction (HAND)	Right Hand
Cutting Item Count (CICT)	2
Depth of Cut Maximum (APMX)	0.37"
Front Type	B
Head Length (LH)	2-1/2"
Master Insert Identification (MIID)
Overall Length (OAL)	6"
Ramping Angle Maximum (RMPX)	90 Degrees
Shank Type	Weldon
