E-SCLCR 10-3 HEAD-Interchangeable screw clamped boring heads carrying 80° rhombic inserts with positive 7° clearance mounted on carbide bars.

Dostępność: duża ilość

Cena brutto: 472,14 zł

zawiera 23,00% VAT, bez kosztów dostawy

Cena regularna:

472.14

Cena netto: 383,85 zł

bez 23,00% VAT i kosztów dostawy

Cena regularna:

Cena w innych sklepach: 524,60 zł

ilość szt.

towar niedostępny

dodaj do przechowalni

Ocena:

Producent:

Kod produktu: 3602216

E-SCLCR 10-3 HEAD

Podstawowe informacje
FamilyName	E-SCLCR/L-HEAD
ToolType	Tool
Unit	I
PackSize	1
product_code	ISC3602216
ProductName	E-SCLCR 10-3 HEAD
COO	Israel
UOM	EA
UNSPSC	23242106
FamilyDesc	Interchangeable screw clamped boring heads carrying 80° rhombic inserts with positive 7° clearance mounted on carbide bars.
FamilyShortDesc	Screw Clamped Boring Heads Carrying 80° Rhombic Inserts with Positive 7° Clearance Mounted on Carbide Bars
Link	https://www.Iscar.com/ecat/e.asp?cat=3602216
Remarks
FamilyBrand	Iscar
BrandName	Iscar
Application	\| Int. 80° Diamond 95° Approach \|
APP1Name	Int. 80° Diamond 95° Approach
ItemRemark
Tool Type	Internal Indexble -Turn Tool
Point Shape
Measurement Type	Inch
Thread Standard
Package Weight	0.1543
Style
MSDS	07995
LocalField1	2
Body Material	Carbide
ManufacturerNo	3602216
Connection Diameter Machine Side (DCONMS)	5/8"
Coolant Supply Property (CSP)	Coolant Thru
Cutting Direction (HAND)	Right Hand
Functional Width (WF)	0.43"
Master Insert Identification (MIID)	CCMT/CCGT 3
Minimum Bore Diameter (DMIN)	0.787"
Overall Length (OAL)	7"
Rake Angle Axial (GAMP)	0 Degrees
Rake Angle Radial (GAMF)	-6 Degrees
Reduced Body Diameter Length (LDRED)	1.17"
Shank Height (H)	0.59"
