ETS D32/1.26-4-LN08-MMT10-Grooving and slitting cutters with MULTI-MASTER threaded adaptor, that mount tangentially clamped inserts with 4 cutting edges.

Dostępność: duża ilość

Cena brutto: 3 677,22 zł

zawiera 23,00% VAT, bez kosztów dostawy

Cena regularna:

3677.22

Cena netto: 2 989,61 zł

bez 23,00% VAT i kosztów dostawy

Cena regularna:

Cena w innych sklepach: 2 545,60 zł

ilość szt.

towar niedostępny

dodaj do przechowalni

Ocena:

Producent:

Kod produktu: 3107230

ETS D32/1.26-4-LN08-MMT10

Podstawowe informacje
FamilyName	ETS-LN08-MM
ToolType	Tool
Unit	M
PackSize	1
product_code	ISC3107230
ProductName	ETS D32/1.26-4-LN08-MMT10
COO	Israel
UOM	EA
UNSPSC	23242106
FamilyDesc	Grooving and slitting cutters with MULTI-MASTER threaded adaptor, that mount tangentially clamped inserts with 4 cutting edges.
FamilyShortDesc	Grooving and Slitting Cutters with MULTI-MASTER Threaded Adaptator
Link	https://www.Iscar.com/ecat/e.asp?cat=3107230
Remarks	For adaptation, click on More Info
FamilyBrand	Iscar
BrandName	Iscar
Application	\| Side Slotting \| Slitting \| T Slotting \|
APP1Name	T Slotting
APP2Name	Side Slotting
APP3Name	Slitting
ItemRemark
Tool Type	Double-sided slotting cutters
Point Shape
Measurement Type	Metric
Thread Standard
Package Weight	0.0780
Style
MSDS	07995
LocalField1	2
Body Material	Steel
ManufacturerNo	3107230
Connection Code Machine Side (CCMS)	MultiMaster
Connection Diameter Machine Side (DCONMS)	15.2 mm
Cutting Diameter (DC)	32 mm
Cutting Item Count (CICT)	4
Flute Count (NOF)	4
Master Insert Identification (MIID)	LNET 082604-TN-N
Overall Length (OAL)	24.3 mm
Peripheral Effective Cutting Edge Count (ZEFP)	2
