XNHU 130608PNN-PL IC808-Square inserts with 4 right- and 4 left-hand cutting edges.

Dostępność: duża ilość

Cena brutto: 100,23 zł

zawiera 23,00% VAT, bez kosztów dostawy

Cena regularna:

100.23

Cena netto: 81,49 zł

bez 23,00% VAT i kosztów dostawy

Cena regularna:

Cena w innych sklepach: 111,37 zł

ilość szt.

towar niedostępny

dodaj do przechowalni

Ocena:

Producent:

Kod produktu: 3335913

XNHU 130608PNN-PL IC808

Podstawowe informacje
FamilyName	XNMU 13
ToolType	Insert
Unit	M
PackSize	10
product_code	ISC3335913
ProductName	XNHU 130608PNN-PL IC808
COO	Israel
UOM	EA
UNSPSC	23242105
FamilyDesc	Square inserts with 4 right- and 4 left-hand cutting edges.
FamilyShortDesc	Square Inserts with 4 Right- and 4 Left-Hand Cutting Edges
Link	https://www.Iscar.com/ecat/e.asp?cat=3335913
Remarks
FamilyBrand	Iscar
BrandName	Iscar
Application	\| Bottom Shouldering \| Facing \| Shouldering \| Side Slotting \| Slotting \| T Slotting \|
APP1Name	T Slotting
APP2Name	Bottom Shouldering
APP3Name	Facing
APP4Name	Shouldering
APP5Name	Side Slotting
APP6Name	Slotting
ItemRemark
Coating	TiAlN+AlTiN+TiN
Cutting Edge Material	Carbide
Tool Type	Double sided Inserts
Point Shape
Measurement Type	Metric
Applicable Material	\| Steel \| Stainless Steel \| Cast Iron \| Hard Materials \| Super-Alloys / Titanium \|
Thread Standard
Package Weight	0.0134
Style
MSDS	07999
LocalField1	2
Body Material	Carbide
ManufacturerNo	3335913
Grade	IC808
Corner Radius (RE)	0.8 mm
Insert Length (INSL)	13 mm
Insert Included Angle (EPSR)	90 Degrees
Insert Thickness (S)	8.8 mm
Maximum Feed per Tooth (fz(max))	0.2 mm/tooth
Minimum Feed per Tooth (fz(min))	0.08 mm/tooth
Number of Cutting Edges	8
