XNMG 120408-F3M IC807-Double-sided 70° Rhombic Inserts for Stainless Steel Finishing Applications

Dostępność: duża ilość

Cena brutto: 58,46 zł

zawiera 23,00% VAT, bez kosztów dostawy

Cena regularna:

58.46

Cena netto: 47,53 zł

bez 23,00% VAT i kosztów dostawy

Cena regularna:

Cena w innych sklepach: 51,60 zł

ilość szt.

towar niedostępny

dodaj do przechowalni

Ocena:

Producent:

Kod produktu: 3396495

XNMG 120408-F3M IC807

Podstawowe informacje
FamilyName	XNMG-F3M
ToolType	Insert
Unit	M
PackSize	10
product_code	ISC3396495
ProductName	XNMG 120408-F3M IC807
COO	Israel
UOM	EA
UNSPSC	23242105
FamilyDesc	Double-sided 70° Rhombic Inserts for Stainless Steel Finishing Applications
FamilyShortDesc	Double-sided 70° Rhombic Inserts for Stainless Steel Finishing Applications
Link	https://www.Iscar.com/ecat/e.asp?cat=3396495
Remarks	For dimensions and tolerances, see more info.
FamilyBrand	Iscar
BrandName	Iscar
Application	\| Ext. 70° Diamond 93° Approach \|
APP1Name	Ext. 70° Diamond 93° Approach
ItemRemark
Coating	TiAlN+TiN
Cutting Edge Material	Carbide
Tool Type	Turn Negative Inserts
Point Shape
Measurement Type	Metric
Applicable Material	\| Steel \| Stainless Steel \| Cast Iron \| Hard Materials \| Super-Alloys / Titanium \|
Thread Standard
Package Weight	0.0131
Style
MSDS	07999
LocalField1	2
Body Material	Carbide
ManufacturerNo	3396495
Grade	IC807
Chip Breaker Type	F3M
Corner Radius (RE)	0.8 mm
Cutting Edge Length (L)	13.52 mm
Depth of Cut Maximum (APMX)	1.5 mm
Inscribed Circle Diameter (IC)	12.7 mm
Insert Thickness (S)	4.76 mm
Insert Size	432-F3
Max. Turning Feed (ft(max))	0.25 mm/rev
Min D.O.C.	0.5 mm
Min. Turning Feed (ft(min))	0.1 mm/rev
